News & Updates…

AJA T-Tap Pro on Desk

AJA Announces T-TAP PRO and Desktop Software v16

AJA is excited to introduce T-TAP Pro. Ideal for a range of production scenarios, the compact, silent and portable Thunderbolt 3-connected device, simplifies 4K/UltraHD and 2K/HD/SD monitoring and output over 12G-SDI and HDMI 2.0 on compatible Mac or PC computers. It silently provides high quality video monitoring including High Dynamic Range (HDR) support for high frame rate (HFR) and large raster workflows from a Thunderbolt 3 host system. Plus, out of the box it’s compatible with Apple Final Cut Pro, Adobe Premiere Pro and After Effects, Avid Media Composer and ProTools, and much more!

Alongside T-TAP Pro, AJA has released Desktop Software v16, a feature rich update that introduces HDR signaling over SDI, auto HDR capture and playback options in AJA Control Panel, enhanced 8K workflows for KONA 5 with Apple Final Cut Pro and Avid Media Composer, expanded IP video support and more. Desktop Software v16 includes compatibility updates for the latest macOS, Windows and Linux operating systems, and enhances and expands support for high-end computer hardware. v16 also increases compatibility with NMOS compliant devices and adds improved troubleshooting capabilities with new LLDP support for KONA IP, Io IP, and Avid Artist | DNxIP. With Desktop Software v16, HDR over SDI is also now available on select AJA KONA, Io products, and the new T-TAP Pro device.

Learn More

AJA OG-12GM with Frame

AJA Releases Two New 12G-SDI openGear® Solutions

AJA Video Systems today announced the release of two new 12G-SDI openGear® solutions, AJA OG-12GM and AJA OG-FiDO-TR-12G. Featuring support for up to 4K/UltraHD content, OG-12GM is a 12G-SDI to/from quad-link 3G-SDI Muxer/DeMuxer, and OG-FiDO-TR-12G is a state-of-the-art 12G-SDI/Fiber transceiver. Both are designed for use in high-density openGear 2RU frames and compatible with Ross® DashBoard software for flexible device control and monitoring.

“As demand for high raster 4K/UltraHD content increases, convenient 12G-SDI solutions are critical to simplifying cabling and transport of high bandwidth content,” said Nick Rashby, President, AJA Video Systems. “In response to industry demand, we’re bolstering our lineup of 12G-SDI workflow tools with the new OG-12GM card and OG-FiDO-TR-12G transceiver, which feature industry-wide compatibility in openGear frames.”

Learn More

AJA Ki Pro GO Front

Ki Pro GO v3.0 Update

AJA has released Ki Pro GO v3.0 firmware for its multi-channel H.264 recorder and player, introducing expanded recording options with new network based recording and support for SMB protocols via GigE network connectivity. Ki Pro GO v3.0 enables any channel to be recorded directly to a network attached storage (NAS) device via Ki Pro GO’s integrated GigE port, providing a central location for primary or backup recording channels independent of local USB storage.

  • Added the ability to use network storage (“NAS”) as a record and playback location via several SMB dialects
  • Fixed issue where illegal names could be added through the Gang page
  • Fixed issue where audio meters on super out ch2 were being duplicated on ch4
  • Fixed issue where SDI embedded audio input had a periodic tick
  • Improved playback stability
  • Various system performance and stability improvements.

Learn More

AJA Bridge Live


AJA Video Systems today unveiled BRIDGE LIVE, a turnkey 1RU solution that makes it easy to move UltraHD or multi-channel HD video between uncompressed baseband SDI to/from a wide range of streaming and contribution codecs (H.265, H.264, MPEG-2 and JPEG 2000). BRIDGE LIVE supports a flexible array of containers and protocols, including SRT, RTMP/S, RTP, UDP and MPEG-TS, and extends to Adaptive Bitrate (ABR) ladder profiles and hand off for OTT packaging. Combining AJA’s production proven I/O technology with Comprimato’s powerful encoding/decoding/transcoding software, this new gateway solution provides high-quality, cost-effective video processing, with SDI encode or decode for one channel of UltraHD up to 60p, or up to four channels of 1080 60p HD simultaneously, via four 12G-SDI connections that are also backwards compatible to 6G, 3G, and 1.5G SDI. A plug-and-play device featuring deep metadata support, BRIDGE LIVE suits a range of professional and enterprise-level video workflows with a 1RU profile that fits seamlessly into facility racks, production trucks and flyplacks. AJA also offers the option of a perpetual BRIDGE LIVE license for encoding/decoding of pristine JPEG 2000 VSF TR-01.

Learn More

AJA OG-12GDA-2x4

OG-12GDA-2×4 now shipping!

The new openGear 12G-SDI distribution amplifier featuring dual-channel inputs for incoming 12G-SDI signals, with re-clocking of the distributed signals to dual 4x 12G-SDI outputs. The new card features compatibility with OGX, OG3 and DFR-8321 openGear frames, and DashBoard software support on Windows, macOS, and Linux for remote monitoring.


Apple Mac Pro and Kona 5

AJA Desktop Video v15.5.1, Kona & the new Mac Pro

*CORRECTION: While the statement that the Mac Pro supports the PCIe powered version of Kona 5 is correct, the claim it does not support ATX power is incorrect. There are ATX power connectors on the new Mac Pro and cable kits are available to connect cards that require this power. For example, these from Belkin: https://www.apple.com/shop/product/HMUJ2ZM/A/belkin-aux-power-cable-kit-for-mac-pro

The AJA Kona 5 needs power. In traditional computers – and some Thunderbolt PCIe Expansion systems (eg. Sonnet Echo Express IIIe) – this power is supplied via an ATX connector at the back directly from the power supply. The new Mac Pro however can pump all the power required through the PCIe slots!

This means that you need to ensure that you order the correct Kona 5 model to suit your system. New Mac Pro owners should ensure they are ordering the KONA-5-R0-S01 supporting PCIe power. Most other systems will likely be using the KONA-5-R0 supporting ATX Power.

Further to this, the new Mac Pro ships with Catalina and as such, AJA have a shiny, new version of Desktop Video Software – v15.5. This release adds not just Catalina, but also Metal support, as well as expanded HDR and 8K capabilities!


Current List of tested & supported PCIe cards for Mac Pro:

Current List of tested & supported Thunderbolt devices for Mac Pro:
Io 4K Plus
Io 4K

AJA HELO Connections

HELO v4.1 Available for Download

Network Recording Enhancements & Performance Improvements
HELO v4.1 introduces a host of performance improvements and new support for SMB level 2.0, 2.1 and 3.0, in addition to new RTMP user selectable modes to improve server/CDN connections.



OG-ROI-DVI and OG-ROI-HDMI now shipping!

Featuring DVI or HDMI to SDI region-of-interest scaling, scan conversion and image rotation in the openGear format. Each card is designed for use in openGear 2RU frames, and can be remotely configured and monitored over a PC or local network using DashBoard software.


AJA FS Mini Converter Top

FS in a Mini Converter

The FS-Mini is a new broadcast quality utility frame sync that packs the production-proven functionality and all of the reliability of AJA’s leading FS frame sync technology into a portable Mini-Converter. FS-Mini supports frame synchronisation and up, down, cross-conversion of untimed 3G-SDI, HD and SD video signals.

FS-Mini allows users to synchronise and convert a wide range of video formats to their house standard with a 3G-SDI input and output, HDMI output, and a two-channel RCA style audio output Mini-Converter. The device also features a reference input that can be used to lock a local reference and can be easily controlled via local DIP switches or USB and AJA’s Mini-Config application.

Available to Order Today

AJA Desktop v15.5

Introducing Desktop Software v15.5 for KONA, Io and T-TAP products

Desktop Software v15.5 highlights include:

  • Full compatibility with macOS Catalina
  • New Metal support on macOS
  • Full 2SI SMPTE raster support for 8K on KONA 5
  • RGB support for 8K capture and playback on KONA 5
  • HDR Test Patterns in AJA Control Panel
  • New DirectShow support for KONA 5 and KONA IP
  • Multiple enhancements across AJA Control Panel and AJA Control Room
  • Support for Windows®, Linux® and macOS®

“Desktop Software v15.5 is targeted at helping users achieve their intended creative vision, no matter the format or desktop operating system,” said Nick Rashby, President, AJA Video Systems. “Our KONA and Io products offer unprecedented connectivity, and the newest software upgrade features even better support for 8K workflows and new enhancements to power creative workflows on Windows, Linux and the latest macOS.”

Available later this year.

AJA Kumo 6464-12g

AJA Debuts KUMO 6464-12G at IBC 2019

AJA Video Systems unveiled KUMO 6464-12G, a new SDI router featuring 64x 12G-SDI inputs and 64x 12G-SDI outputs for high quality, cost-effective signal routing. KUMO 6464-12G suits a range of broadcast, production, post, and proAV environments and allows professionals to take advantage of the scalability, security, and increased bandwidth that 12G-SDI provides.

With KUMO 6464-12G, professionals can easily route and control video with embedded audio to/from BNC connections with auto reclocking of SDI rates. The KUMO routers can be configured for ganged dual and quad-port routing, so that users can easily combine multiple inputs and outputs for Dual Link, 4K, UltraHD and 8K workflows, enabling seamless routing of uncompressed, compressed, or Raw 4K signals throughout a facility.

Learn More

New v2.2 firmware update that introduces a host of performance improvements for its IP Mini-Converter receivers, including new UltraHD support up to 50p for IPR-10G2-HDMI and IPR-10G-HDMI, as well as Reference Input support for IPR-10G2-HDMI and IPR-10G2-SDI

Dolby Vision support is expected to soon be available for its Hi5-4K-Plus and Hi5-12G Mini-Converters via an upcoming firmware release. The update will make it easier for creative professionals to achieve their artistic visions by enabling the conversion of Dolby Vision encoded HDR content on SDI to be converted to HDMI for PQ HDR monitoring on affordable HDMI displays.

AJA HDR Image Analyzer 12G on Desk

AJA brings 12G-SDI connectivity to its powerful real-time HDR monitoring and analysis platform.

AJA Video Systems announced the new HDR Image Analyzer 12G, bringing 12G-SDI connectivity to its powerful real-time HDR monitoring and analysis platform developed in partnership with Colorfront. The new product streamlines 4K/UltraHD HDR monitoring and analysis workflows by supporting the latest high-bandwidth 12G-SDI connectivity.

“Since its release, HDR Image Analyzer has powered HDR monitoring and analysis for a number of feature and episodic projects around the world. In listening to our customers and the industry, it became clear that a 12G version would streamline that work, so we developed the HDR Image Analyzer 12G which we’re proud to showcase at IBC this year,” shared Nick Rashby, President, AJA Video Systems.

AJA Corvid 44 12G and LP

Corvid 44 12G Now Shipping

Take command of the most challenging projects using the immense power of the newest member of the Corvid product line. Corvid 44 12G is AJA’s blazingly fast, compact 8-lane PCIe 3.0 I/O card with four bidirectional 12G-SDI HD BNC connections, designed for today’s most demanding video and audio workflows.

“Growing consumer appetite for ever higher quality content is prompting more professionals to deliver in 4K and 8K. Corvid 44 12G arrives at a prime time, giving Developers access to powerful I/O technology to create solutions that streamline how high resolution, deep colour content is created and delivered,” shared Nick Rashby, President, AJA Video Systems.

AJA HDR Roadshow

HDR Roadshow highlights AJA Video’s Complete HDR Workflow Solutions

What is HDR?

The pursuit of High Dynamic Range (HDR) is the dream of getting closer to the Human Visual System (HVS) in all that we experience as viewers.

  • HDR is a new display system that is designed to better represent what the human vision system (HVS) can see.
  • Human vision sees the world with lots of dynamic range and a wide range of colours.
  • Modern cameras have up to 14 stops of dynamic range.
  • BT.709 Standard Dynamic Range (SDR) systems can show only up to the equivalent of about 6 stops.
  • HDR attempts to show much more of the world we see, starting with the larger camera dynamic range available today at source and through the production chain and ultimately for presentation on affordable displays optimised for HDR.

You may have missed the event, but if you are interested in understanding more about HDR and the tools available check out their comprehensive HDR Solutions Site, or speak to Broadcast Bruce.

AJA Solutions:

AJA FS1-X Back Large

FS1-X New v1.1.2 Firmware!

FS1-X v1.1.2 is now available for download, a free maintenance update that includes several important enhancements addressing image quality.

Video output is improved to remove possible artifacts when downscaling.
Improved image quality when the Frame Rate Converter (FRC) option is installed and enabled.

Learn More About FS1-X with FRC

AJA Kumo 3232-12G

AJA Kumo Routers & Control Panels Receive v4.5 Firmware Upgrade

This version of KUMO firmware adds support and improvements for KUMO-12G routers and one key feature for all KUMO products. All users of KUMO products are encouraged to update to the latest firmware.

Added IP configuration for all AJA KUMO routers and control panels (over USB port) using eMiniSetup v2.0.0 and later.

Improves the SDI performance in KUMO-1616-12G and KUMO-3232-12G. All KUMO 1616-12G and 3232-12G products should be updated to v4.5.0.

Kumo 3232-12GKumo 1616-12G

IPT-10G2-HDMI & IPT-10G2-SDI — SMPTE ST 2110 Mini-Converters – Now Shipping!

The two new models are single channel IP video transmitters for bridging traditional HDMI and 3G-SDI signals to SMPTE ST 2110 for IP-based workflows.

The converters are suited for broadcast studios, sports trucks, newsrooms, enterprise media facilities, stadiums, concerts and other live event and professional AV environments

Learn More: IPT-10G2-HDMI / IPT-10G2-SDI

Fourteen New openGear Rackframe Cards with DashBoard Support!

  • Re-clocking SDI distribution amplifiers
  • Single-mode 3G-SDI fibre converters
  • Multi-Mode 3G-SDI fibre converters
  • SDI audio embedder/disembedder

For critical broadcast applications, AJA openGear compatible converter cards provide the highest levels of quality and reliability for use in openGear frames including the new AJA OG-X-FR. AJA offers cards for infrastructure, HDMI/SDI conversion, Fiber conversion and scaling. All new AJA openGear are DashBoard software compatible, allowing easy configuration and control.

Learn More

AJA FS-HDR 1U Frame Sync Universal Converter

FS-HDR v3.0 Firmware with enhanced colouring tools and support for multi-channel Dynamic LUTs and Improvements for broadcast, on-set, post and proAV HDR production:

  • New Colorfront Engine™ Film Mode
    • Input Dynamic Range and Gamut: Support for a broad range of selections including SDR, PQ, HLG, HLG Extended, Sony Slog3, ARRI Log C, Panasonic V-Log, Red Log3G10, Canon Log 2 and Log3, ACEScct
    • Output Dynamic Range and Gamut: Support for a variety of selections including SDR, PQ, HLG, HLG Extended, Sony Slog3, ARRI Log C and ACEScct
    • Nit Level Control for PQ Output: Variable adjustments from 48-4000 Nits
    • DCI P3 Colorspace Clamp for HDR Output
    • SDR Preview for HDR Output
    • HDR Amount and Ambient Surround Compensation
    • LOOK: Look A Select, Look B Select and A/B Mix
      • Includes 23 different optional Looks including popular film emulation with Bleach, Ektachrome, Kodachrome, ARRI K1S1, FujiXD and more.
    • Grading Colorspace Selection: LogC, ACESscct, and SLog3
    • ASC CDL Defined Parameters: Slope, Power, Offset, and Saturation
    • Scene Referred Adjustments: Exposure, Color Temp and Tint
  • Colorfront Engine Live Mode for Transforms with New Additions:
    • Input/Output Dynamic Range: Support for HLG Extended
    • Nit Level Control for PQ Output: Variable adjustments from 48-4000 Nits
    • DCI P3 Colorspace Clamp for HDR Output
  • Updated BBC v1.3 LUTs: This update includes the latest improvements to the BBC’s licensed HLG conversion LUTs
  • Single-channel and Four-channel Dynamic LUT Mode Integrates with:
    • Pomfort LiveGrade Pro
    • TV Logic WonderLookPro

DownloadMore About FS-HDR

AJA HDR Image Analyzer with Colorfront

HDR Image Analyzer v1.1 Firmware

  • New Web UI with support for remote updates, log and screenshot transfers
  • Remote Desktop support
  • UI enhancement for HDR/PQ display over DisplayPort
  • Automated Colour Space switching over SDI for SDR/PQ/HLG
  • Out of Gamut MAX warning: Provides notice if colour goes outside of P3d65
  • Frame average Light Level (LL) bar
  • Vectorscope enhancements
  • TC bypass improvements

DownloadHDR Image Analyzer

AJA Ki Pro Ultra Plus Connections

AJA Releases Ki Pro Ultra Plus v4.0 Firmware

Packed with new features, the update advances recording customisation – supporting file naming, time code super out controls, and audio channel mapping! The following features have been added or revised for v4.0 firmware:

  • Forced Rollover: when rollover mode is enabled, the SLOT button can now be held down to activate the rollover at any time, allowing continuous recording to a second Pak drive and providing rollover conditions are met.
  • Analogue/AES audio mapping: users are able to select pairs of Analogue and AES audio and assign them by input, according to their needs, in addition to the previous options of SDI, AES or Analogue.
  • Move-able time code burn-in: There are now six user select-able positions available for the time code burn-in feature.
  • Independent multi-channel fle naming: Users can now add a ‘channel identifier’ to each clip, in addition to the previously available naming options.
  • RS-422 ID selection: Ki Pro Ultra Plus now offers three user selections for the RS-422 ID; Ki Pro Ultra, Ki Pro Rack and Sony’s SRW-5500.

Release Notes – DownloadProduct Details

AJA IPR-10G2-SDI Front

AJA Expands IP Mini-Converter Portfolio

AJA Video Systems today announced new IPR-10G2-HDMI and IPR-10G2-SDI SMPTE ST 2110 video and audio receivers featuring new dual 10 GigE SFP+ cages that provide hitless switching for redundancy protection in critical distribution and monitoring applications and support for bridging UltraHD or HD signals over IP to HDMI or SDI. The IPR-10G2-HDMI and IPR-10G2-SDI support monitoring of SMPTE 2110 signals via HDMI (up to UHD p30) and 3G-SDI (up to HD p60) respectively. Both feature a reference-in via BNC for seamless integration into existing baseband environments such as master control, trucks or edit suites.

Press Release



KONA HDMI is highly flexible PCIe capture card, designed for four simultaneous channels of HD capture, with popular streaming and switching applications including Telestream Wirecast and vMix. KONA HDMI uniquely also offers capture of one channel of UltraHD up to 60p over HDMI 2.0, via AJA Control Room software for file compatibility with most NLE and effects packages. It is also compatible with other popular third party solutions for live streaming, projection mapping and VR workflows. LEARN MORE

AJA Kona HDMI eSports Workflow

AJA Kona 1 Connections


KONA 1 is a robust, cost efficient single channel 3G-SDI 2K/HD 60p I/O PCIe card. KONA 1 offers serial control and reference/LTC, and features standard application plug-ins, as well as AJA SDK support, and is perfect for broadcast, post, proAV, and OEM developers. The new card supports 3G-SDI capture, monitoring and/or playback with software from AJA, Adobe, Avid, Apple, Telestream and others, and enables simultaneous monitoring during capture (pass-through). LEARN MORE

AJA KONA 1 Workflow

AJA Io IP Rear


Io IP is a portable Thunderbolt 3 ingest and playback device for professional HD video and audio over IP, bridging 10 GigE to the most popular creative software applications. Io IP has all the portable benefits of the Io family line with two Thunderbolt 3 ports for flexibility. It works with AJA’s Control Room, Control Panel software and SDK tools, providing support for leading content creation applications, such as Adobe Premiere® Pro, Apple FCP X, Avid Media Composer®, FilmLight products and more. Designed as a flexible platform with support for SMPTE 2022-6 and 2022-7 uncompressed IP video and audio, and SMPTE 2110 to come soon, Io IP offers you the flexibility to keep current as the IP transition proceeds.  LEARN MORE

AJA Io IP Workflow

AJA IPR-10G-HDMI Mini Converter

IPR-10G-HDMI Mini-Converter – Bridge SMPTE 2110 to HDMI over 10 GigE

Easily monitor HD SMPTE ST 2110 signals via HDMI with IPR-10G-HDMI. Our new Mini-Converter receives ST 2110 over 10 GigE and formats the data for output on a full-size HDMI interface. Associated audio is extracted, synchronised and embedded into the HDMI interface and output on an analogue RCA interface. Learn More

IPR-10G-HDMI SMPTE2110 Workflow

AJA Kumo 3232-12G

KUMO 3232-12G and KUMO 1616-12G – New 12G-SDI Compact Routers

Two new 12G-SDI KUMO routers support large format resolutions, high frame rate (HFR) and deep color formats, while reducing cable runs when transporting 4K/UltraHD over SDI. The routers offer network based and/or physical control, adding a new USB port for configuring IP addresses via AJA’s eMini-Setup software. Multi-port gang-routing also means the new 12G-SDI models are 8K ready! More on KUMO 3232-12G / KUMO 1616-12G
