Core SWX Apex 360HV


This PRE-ORDER is ESTIMATED to be charged and shipped February 6, 2023. READ OUR PRE-ORDER POLICY

Core SWX Apex 360HV – 29.6V 367wh Lithium V-Mount Battery

367Wh Li-Ion V-Mount Battery
High-Capacity, High-Voltage 29.6V Output
Cooler Operation at Lower Currents
5-Stage LED Status Gauge
Designed for Lighting Equipment
Supports up to 12A Continuous Draw
Helix System Pin Set for Use on 14V Gear
Approximately 2 Hours of Runtime


Core SWX Apex 360HV


Core SWX Apex 360HV
29.6V 367wh Lithium V-Mount Battery

Core SWX APEX Batteries on Aputure

Power your professional lighting equipment for long periods with the APEX 360HV High-Capacity 29.6V/367Wh High-Voltage Li-Ion V-Mount Battery (Helix Compatible) from Core SWX. This rugged, high-capacity battery features a high 29.6V output and 367Wh capacity, and it supports a continuous 12A draw. It is designed with cooler operation for use with professional lighting equipment such as Aputure lights.

The battery provides approximately two hours of battery life when tested on certain fixtures at 100% brightness. The 5-stage LED gauges show the battery level status, and they can be viewed from all sides of the battery. The battery can be charged on a Core SWX APEX V-mount charger.

Key Features

The APEX 360 features a high-voltage 29.6V output and 367Wh capacity
Five-stage LED gauges display the battery power level and can be viewed on all sides
You can charge the battery on a Core SWX APEX high-voltage V-mount charger
Compatible with Helix mounts with pin set design for use on 14.4V gear
Durable casing ensures cool operation, making the battery ideal for powering lights

Compatible with but not limited to:

Aputure 300D II
Aputure 600D
Aputure Nova P300C

Core SWX Apex 360HV Specs

Mount / Series Type: V-Mount
Chemistry: Lithium-Ion
Battery Capacity: 367 Wh
Output Voltage: 29.6 VDC
Maximum Load: 12 A
Accessory Port: None
Dimensions (W x H x D): 88.9 x 160 x 96.5 mm
Weight: 1633 g

In the Box

Core SWX APEX 360 High-Capacity 29.6V/367Wh High-Voltage Li-Ion V-Mount Battery (Helix Compatible)
Limited 1-Year Warranty
